Trumpf 2534316 Cordless Sheet Metal Shear for 0.063 Inch Mild Steel Cutting - Solo Tool
- Part #:2534316
- Model #:TruTool S 160
- Condition:Brand New

Battery and charger are not included. Purchase the TRUMPF 2598817 12V Starter Kit separately; it includes two 12V LiHD 4.0 Ah rechargeable batteries and one LG 12V–36V charger.
Key Facts
- TRUMPF 2534316 TruTool S 160 cordless sheet metal shear with a 12V LiHD battery platform.
- Cuts mild steel up to 0.063 inch (1.6 mm) thick at a tensile strength of 400 N/mm².
- Compact shearing head supports straight cuts, curves, and sheet metal trimming.
- Solo configuration: battery and charger are not included.
- Compatible US 12V Starter Kit 2598817 is sold separately and includes two 12V LiHD 4.0 Ah batteries and one LG 12V–36V charger.
Overview
The TRUMPF TruTool S 160 is a handheld cordless shear for cutting flat sheet metal and following curved cutting paths. It supports fabrication, HVAC sheet metal work, and installation tasks requiring a compact tool that can move around the workpiece.
The short body and compact cutting head help with maneuvering around contours. A brushless motor and TRUMPF Power-Head Technology support battery-powered cutting, while four-sided cutting blades provide multiple usable cutting edges.
Part number 2534316 is the solo version supplied in a TRUMPF box. Order this configuration if you already have a compatible battery and charger, or purchase Starter Kit 2598817 separately.
Features
- Compact head for guiding the shear through curved sheet metal cuts.
- Cordless operation for moving between cutting locations without routing a power cord.
- Four-sided, replaceable cutting blades for continued use as individual edges wear.
- Brushless motor for efficient cordless operation.
- Material-specific cutting capacities for selecting the tool according to sheet thickness and tensile strength.
Technical Specifications
- Manufacturer: TRUMPF
- Part number: 2534316
- Model: TruTool S 160
- Battery voltage: 12V
- Maximum steel thickness at 400 N/mm²: 0.063 inch (1.6 mm)
- Maximum steel thickness at 600 N/mm²: approximately 0.047 inch (1.2 mm)
- Maximum steel thickness at 800 N/mm²: approximately 0.039 inch (1.0 mm)
- Maximum aluminum thickness at 250 N/mm²: approximately 0.079 inch (2.0 mm)
- Maximum working speed: approximately 29.5 ft/min (9 m/min)
- Smallest cutting radius: approximately 0.63 inch (16 mm)
- Starting hole diameter: approximately 1.10 inches (28 mm)
- Battery included: No
- Charger included: No
Compatibility
Use a compatible TRUMPF 12V LiHD battery and approved charger. TRUMPF identifies this tool with the 12V Cordless Alliance System platform; verify the specific battery and charger combination before ordering.
The separately available US Starter Kit 2598817 supplies two 12V LiHD 4.0 Ah rechargeable batteries and one LG 12V–36V charger. Part number 2598817 identifies the starter kit, rather than an individual battery.
Use Cases
- Cutting flat sheet metal to size for fabrication work.
- Trimming sheet metal components during HVAC installation.
- Following curved outlines and radial cutting paths.
- Portable cutting during sheet metal fitting and maintenance.
What’s Included
- TRUMPF TruTool S 160 cordless shear
- Standard cutter
- SW 2 and SW 3 hex wrenches
- Belt clip
- TRUMPF storage box
Battery and charger are sold separately.
Category FAQs
How should I choose a shear for a particular sheet metal grade?
Check both thickness and tensile strength. A thickness rating for mild steel does not establish the same capacity for stronger steel.
Can I select this tool using sheet metal gauge alone?
Confirm the actual thickness and material grade because gauge designations vary by metal type.
What should I check before cutting stainless steel?
Identify the stainless steel grade and tensile strength, then verify the applicable cutting capacity and cutter selection.
What matters when planning an internal cutout?
Allow room for the starting opening and cutting head, and check that the planned contour meets the tool’s minimum radius.
Will every 12V battery fit?
No. Voltage alone does not establish compatibility. Confirm the battery platform and approved pairing.
When should I consider another cutting tool?
Consider a different tool when the material exceeds the rated capacity or the workpiece geometry prevents access with the shearing head.
How should I prepare for repeated cuts?
Support the sheet, mark the cutting path, and plan access around the workpiece before starting.
What should I verify when ordering replacement cutters?
Match the cutter to the TruTool S 160 and the intended material. Do not assume cutters for another TRUMPF shear are interchangeable.
- Specification Sheet
- Accessories
- You May Also Like
- Your Recently Viewed
- Reviews
- Q&A
| Smallest radius | 16 mm |
| Working speed (max.) | 9 m/min |
| Starting hole diameter | 28 mm |
| Nominal power consumption | 12 V |
