Solinst 114232 Telemetry System - LTE (EMEA / APAC)
- Part #:114232
- Model #:9100
- Condition:Brand New
Telemetry System - LTE (EMEA / APAC)
STS Telemetry Systems are designed for use with high quality dataloggers. Using a 4G LTE cellular modem, the STS sends water level, temperature, conductivity and rainfall data from the field to a Home Station PC. STS Remote Stations can be powered by a sealed lead-acid 12V battery, and optionally, solar trickle charging or direct AC power. Up to four dataloggers can be connected to one STS. Two-way IP communication from your desktop allows added features such as alarm notification, remote diagnostic reporting, and remote updates, which makes it easy to maintain your system, while simplifying data collection. STS Telemetry Systems are ideal for large networks. Hundreds of remote stations can report to a single Home computer.
Features
- Intuitive software for easy programming and setup
- IP communication for reliable data transfer
- Simplified, more reliable service provider connection using SIM card
- Database to import to your own website or list
- Allows barometric compensation of remote water level data
- Remote schedule and firmware updates from the Home Station
- Battery level and status updates with each report
- GPS module in remote STS allows location mapping in Solinst Telemetry Software
- High or low level alarm notifications
- Specification Sheet
- Manuals/Tutorials
- You May Also Like
- Your Recently Viewed
- Reviews
- Q&A
| Communication: | Static IP at Home Station PC and Dynamic IP at remote STS, e-mail alarm notifications |
| Antennas: | 700/850 MHz BLADE SMA Male |
| Data File Type: | .mdb (database), .xle, .lev or .csv (exported) |
| Sampling Interval: | 10 seconds - 99 hours |
| Reporting Interval: | 5 minutes - 1 week |
| Schedule Programming: | Initial setup and remote updates done through Solinst Telemetry Software at Home Station |
| Power Supply: | 12V, 12-30 AHr deep-cycle, rechargeable sealed lead-acid battery |
| Optional Power Input: | 10V - 16V DC, 15W |
| Battery Life Example: | 1 year: based on hourly sampling and daily reporting (4 dataloggers) |
| Memory Capacity: | 16 MB (Between Reports) |
| Operating Temperature: | -30°C to 50°C |
| Optional Enclosure: | NEMA 4X (IP66: dust and water proof, cannot be submerged) |
| Compatible Dataloggers: | Levelogger 5 Series dataloggers, LevelVent 5, as well as previous versions of the LevelVent and Levelogger Edge Series dataloggers |
| Number of Connected dataloggers: | 4 |
| Barometric Compensation: | Using a connected Barologger, automatically performed in Solinst Telemetry Software or by user in external database |
