Solinst 105452 Continuous Multichannel Tubing, 7 Channel, 200ft Coil
- Part #:105452
- Model #:403
- Condition:Brand New
%20Copyright%202023%20Fonticons,%20Inc.--%3e%3cpath%20fill='%230F615A'%20d='M112%200C85.5%200%2064%2021.5%2064%2048v48H16c-8.8%200-16%207.2-16%2016s7.2%2016%2016%2016h256c8.8%200%2016%207.2%2016%2016s-7.2%2016-16%2016H48c-8.8%200-16%207.2-16%2016s7.2%2016%2016%2016h192c8.8%200%2016%207.2%2016%2016s-7.2%2016-16%2016H16c-8.8%200-16%207.2-16%2016s7.2%2016%2016%2016h192c8.8%200%2016%207.2%2016%2016s-7.2%2016-16%2016H64v128c0%2053%2043%2096%2096%2096s96-43%2096-96h128c0%2053%2043%2096%2096%2096s96-43%2096-96h32c17.7%200%2032-14.3%2032-32s-14.3-32-32-32V237.3c0-17-6.7-33.3-18.7-45.3L512%20114.7c-12-12-28.3-18.7-45.3-18.7H416V48c0-26.5-21.5-48-48-48zm432%20237.3V256H416v-96h50.7zM160%20368a48%2048%200%201%201%200%2096%2048%2048%200%201%201%200-96m272%2048a48%2048%200%201%201%2096%200%2048%2048%200%201%201-96%200'/%3e%3c/svg%3e){kind=small}
Free ShippingContinuous Multichannel Tubing, 7 Channel, 200ft Coil
A multilevel well that uses a continuous length of multichannel tubing has the advantage over other multilevels in that there are no joints. This significantly reduces the time and cost of installing wells and at the same time increases the reliability of the system. The CMT is very simple and convenient to use, as it gives full flexibility as to where monitoring zones are located. The number and location of ports may be determined in advance, or after drilling the borehole. A Port Cutting Guide is used to create a port in a given channel, at the specified depth to be monitored. A plug is positioned and sealed in the channel just below the port opening and a stainless steel screen is fixed in place over the port to prevent fines from entering. Each channel is also sealed at the bottom of the tubing to avoid cross communication between monitoring zones.
- Specification Sheet
- You May Also Like
- Your Recently Viewed
- Reviews
- Q&A
| Material | *MDPE |
| Tubing Outside Diameter | 1.7" (43 mm) |
| Channel Diameter | 6 - Outer pie channels: nominal 0.4" (10 mm) 1 - Center hex channel: nominal 3/8" (9.5 mm) |
| Channel Volume | 40 mL/ft 30 mL/ft (center) |
| Installation Options** | Sand & bentonite backfill Natural formation collapse |
| Coil Lengths*** (Coil 4 ft dia.) | 200 ft (60 m) |
| Tubing Temperature During Installation | -15°C to +35°C **** |
| Port Plug Temperature During Installation | +15°C to +35°C |
| Pressure Differential (Water Levels) | 12.5 inch-pounds torqued port plugs are designed to hold 20 psi (50 ft) of head differential. |
| Note | * Tubing is MDPE; proprietary mix of HDPE and LDPE products. ** Avoid using 'single lifts' of grout, greater than 50 ft in the unsaturated zone. *** Each CMT coil measures 1 to 2 ft longer than stated. **** If air temperature is above +35°C, use cold water to cool down the tubing at the port before installing the port plug. |
