PCE Instruments PCE-TG 120 Ultrasonic Flow Meter, 1 to 30 mm

Material Thickness Meter PCE-TG 120Thickness meter for homogeneous materials / With special test probe for edges and thin tubes / Adjustable ultrasonic speed / Easy operation / May only be used on a clean and flat surface / Not suitable for welding seams (displays in mm only)

The material thickness meter PCE-TG120 is a very easy-to-use wall thickness gauge for all materials. This material thickness meter works to accurately measure the material thickness / wall thickness with ultrasound. Different materials require different ultrasonic speeds. The material thickness meter is factory pre-set with five different sound velocities for different material. With the material thickness meter, you can determine the material thicknesses of metal, glass, plastics and other homogeneous materials in seconds. The speed of sound can be freely adjusted on the thickness meter and thus adapted to a wide variety of materials. The test head of the material thickness meter is designed in such a way that it can easily measure on angular workpieces.The material thickness meter is delivered calibrated. As an accessory, you can order an ISO laboratory calibration including certificate at the time of initial order or recalibration.

Features:

• Suitable for all materials, on small edges and thin tubes
• Including 5 MHz probe
• Resolution 0.1 mm (displays in mm only)
• 4-digit LC display
• Backlight
• Battery status indicator
• Coupling display between probe and test piece
• Automatic calibration
• Integrated 3.0 mm steel block for calibration

Includes:

• 1 x PCE-TG 120 Material Thickness Meter
• 1 x Miniature contact transducer with 1 m (3.3 ft) cable
• 2 x Batteries
• 1 x Bottle of contact gel
• 1 x Carrying strap
• 1 x Carrying case
• 1 x User manual
