PCE Instruments PCE-PTR 200N Force Gauge, 0 to 200 N

PCE-PTR 200N force gage for tensile force measurement and pressure force measurement up to 200 N (45 lbs) USB interface and downloadable evaluation software for data transmission / Many measuring adapters

The PCE-PTR 200N force gage is a hand-held device up to 200 N / 45 lbs. The force measuring device can determine the units N, kg and lb. The PCE-PTR 200N force gage is supplied with various shaped adapters. These can be screwed onto the device and thus offer the optimum solution for differently designed surfaces in the measurement of pressure and tension. In addition to the adapters, an extension rod is also supplied, which allows measurements in hard to reach places. This extension rod has a length of 65 millimeters / 2.6 inches. The PCE-PTR 200N force gage includes a flat head adapter, hook adapter, ball head adapter, chisel head adapter, and a notched head adapter, with the hook adapter used for pulling force measurements.

The PCE-PTR 200N force gage offers the possibility to attach the force measuring device to a test stand by means of threads on the rear of the device. Test stands are always used in a force gage if reproducible measurement results are required during the force measurement. These test stands are ideal additions to a force gage, because they are operated by a precise hand wheel or a motor. In addition, both tensile and compressive force measurements can be performed on them. Experiments in the laboratory are thus possible with the force gage as well as the inspection at the incoming goods inspection.

Features:

• Differently shaped measuring adapter
• Downloadable evaluation software
• Device for mounting on test stands
• Peak measurement
• Power supply via charging adapter
• Delivery with extension rod
• Evaluation via USB interface
• Fast measured value display

Includes:

• 1 x Force Gage (Penetrometer) PCE-PTR 200N
• 1 x Penetration tip Ø 6 mm
• 1 x Penetration tip Ø 8 mm
• 1 x Penetration tip Ø 11 mm
• 1 x Flathead adapter
• 1 x Hook adapter
• 1 x Ball head adapter
• 1 x Chisel head adapter
• 1 x Notch head adapter
• 1 x Extension rod (65 mm)
• 1 x USB cable
• 1 x Power plug
• 2 x Locking rings
• 1 x Equipment case
• 1 x Software
• 1 x User manual
