Midwest Control BLG-HU95-125 1/2 FPT x 1/4 FPT Pilot Valve w/Hand Unloader 1/2 FPT Vent Discharge 95-125 60 SCFM

1/2 FPT x 1/4 FPT Pilot Valve w/Hand Unloader 1/2 FPT Vent Discharge 95-125 60 SCFM

The BG/BLG Piloted Unloader Valves with a Hand Unloader is Used in Gasoline Driven Constant Speed Applications Where There are No Intake Unloaders. A Discharge Unloader and Pilot Valve are Combined Into One Valve to Sense System Pressure and Vent Discharge Air to Atmosphere. At Load Pressure, the Pilot Valve Closes the Discharge Unloader and the Compressor Returns to Normal Operation.

The BG/BLG Piloted Unloader Valves Require a Seperate Check Valve from Which a Line Must be Run to the Discharge Inlet.

Features:

• Construction: Forged Brass Body, Stainless Steel Spring and Pilot Ball Valve with a 15% Glass Filled Teflon Unloader
• Maximum Temperature: 450 F
• Field Adjustable
• Minimum Cut- In Pressure: 40 PSI
• Maximum Cut- Out Pressure: 250 PSI
• Hand Unloader (Used to Manually Unload the Compressor)
• Includes Muffler
