Exair 9074 3/4 NPT Reclassifying Muffler

Features:

• Reclassifying Muffler is an upgrade from a Sintered Bronze Muffler. It offers superior noise reduction - up to 35 dB.
• It is size 3/4 NPT.
• The Reclassifying Muffler also eliminates oil mist. Exhaust air from cylinders and valves often contains oil mist that can contaminate worker's breathing air and negatively affect their health.
• According to OSHA Standard 29 CFR 1910.1000, a worker's cumulative exposure to oil mist must not exceed 5 mg/m³ over an eight-hour shift within a 40-hour work week.
• The patented wrap design of the removable element separates oil from the exhausted air so that virtually no oil is released into the environment.
• Based on an intake of 50 PPM at 100 PSIG, the Reclassifying Muffler reclassifies and reduces exhausted oil mist to 0.015 PPM. A reservoir at the bottom collects the oil and can be drained by attaching a 1/4" tube.
• The Reclassifying Muffler allows a certain volume of air to pass with minimal back pressure restriction, ensuring it does not interfere with the operation of a cylinder or valve.
• The Reclassifying Muffler also eliminates harmful dead-end pressures.
• 3/4 NPT Reclassifying Muffler
