Technical details
Device
Product Type | Dome |
Maximum Resolution | 3MP |
Application Environment | Outdoor |
Image Sensor | Progressive Scan CMOS |
Sensor Size | 1/2.8 " |
Effective Pixels | 2065(H) X 1553(V) (3.21 MP) |
Day / Night | Yes |
Low Light Sensitivity | Superior |
Minimum Illumination | Color: 0.003 lux at F1.8; B/W: 0 lux (IR LED on) |
Color to B/W Switch | ISP based switch, configurable |
Mechanical IR Cut Filter | Yes |
IR Sensitivity Range | 700-1100nm |
IR LED | Adaptive IR LED x 8 (850 nm) |
IR Working Distance | 30m (0 lux, 30IRE, Gain 255, Auto shutter mode) |
Electronic Shutter | 1/5-1/64000 second (manual mode); 1/5-1/64000 second (auto mode) |
Horizontal Resolution (TV Lines) | 1300 TVL |
S/N Ratio | 56 dB |
Lens
Focal Length | Fixed focal, f2.1mm |
Aperture | F1.8 |
Iris | Fixed iris |
Focus | Fixed focus |
Lens Mount | Board mount |
Horizontal Viewing Angle | 117.5° |
Vertical Viewing Angle | 90° |
Viewing Angle Adjustment | Pan: -175°-175°, Tilt: 5°-175°, Rotation: -175°-175° |
Video
Compression | H.265, H.264 (Baseline/ Main/ High profile), MJPEG |
Maximum Frame Rate vs. Resolution | 30 fps at 2048 x 1536; 30 fps at 1920 x 1080; 30 fps at 1280 x 960; 30 fps at 1280 x 720; 30 fps at 800 x 600; 30 fps at 640 x 480; 30 fps at 320 x 240 |
Multi-Streaming | Simultaneous triple streams based on three configurations |
Bit Rate | 128Kbps - 12Mbps (per stream) |
Bit Rate Mode | Constant, Variable |
Wide Dynamic Range | Extreme WDR (145 dB) |
Image Enhancement | White Balance, Brightness, Contrast, Saturation, Sharpness, Automatic gain control, Flickerless, Defogging |
Digital Noise Reduction | 2D + 3D DNR |
Privacy Mask | 4 configurable regions |
Text Overlay | Yes |
Built-in Analytics | Object Based Motion Detection, Tampering Detection, Shock Detection |
Server-based Analytics | Object Line Counting, People Counting, Face Detection, Object Based Motion Detection, Tamper, Object Line Crossing Detection, Object Enter Area Detection, Missing Object Detection, Unattended Object Detection, Smoke Detection, Heat Map, Dwell Time, Direction Detection, Automatic License Plate Recognition, People Queue Detection, (Require PC-based or standalone IVS or ALPR Server. Contact ACTi support for recommendations on how to maximize analytical accuracy) |
Image Orientation | Flip, Mirror, Rotation (Corridor mode) |
Audio
Audio Type | 2-way, Built-in Microphone, Mic-in, Line-in, Line-out |
Audio Compression | 8 kHz, 16 bit encoding, Mono, PCM, G.711 |
Network
Network Protocol & Service | IPv4/v6, TCP, UDP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, NTP, RTP, RTSP, RTCP, SMTP, FTP, IGMP, ICMP, ARP, Bonjour, UPnP, QoS, SNMP, IEEE 802.1X |
Ethernet Port | 1 x RJ-45 pigtail connector |
Security | IP address filtering, HTTPS encryption, Password protected user level, Anonymous login, IEEE 802.1X network access control |
Video Analytics
Event
Event Trigger | Video motion detection (10 included and excluded polygonal regions), External device through digital input, Tampering detection, Shock Detection, Sound detection, Video streams loss, System log buffer overrun, Remove system log, Logon events (Login Failure, Login Success, Block an Account) |
Event Response | Notify control center, Change camera settings, Command other devices, E-mail notification with snapshots, Push notification to mobile device, Save video to local storage, Upload video to NVR server, Upload video or snapshot to FTP server, Activate external device through digital output |
System
System Log | Support |
Watchdog | Support |
Integration
Unified Solution | Fully compatible with ACTi software |
GPS Position | Manual setting |
Edge Recording | Support (integration with NVR by ONVIF Profile G or proprietary protocol)** |
ONVIF Compliant | Yes, Profile S, Profile G, Profile T |
GB28181 Compliant | Yes |
Web Browser | IE 11, Google Chrome*, Microsoft Edge*, Apple Safari* |
Auto Firmware Upgrade | Yes |
Interface
Audio Interface | Built-in microphone, 1/1, Cable with 3.5mm Phone Jack |
Local Storage | MicroSDHC, MicroSDXC memory card slot (card not included) |
Digital Input/Output | 1/1 (Cable with Terminal block) |
General
Power Source | DC 12V, PoE Class 3 (IEEE802.3af) |
Power Consumption | 11 W (PoE, IR on), 10.5 W (DC, IR on) |
Weight | 566g (1.25lb) |
Dimensions | (Dia. x H): Outdoor: 115mm x 87mm (4.53" x 3.43") |
Environmental Casing | Weatherproof (IP68), Vandal proof (IK10) |
Mount Type | Surface, Wall Mount, Pendant, Flush, Pole Mount, Gang Box |
Starting Temperature | -40°C ~ 60°C (-40°F ~ 140°F) |
Operating Temperature | -40°C ~ 60°C (-40°F ~ 140°F) |
Operating Humidity | 10% - 85% RH |
Approvals | CE (EN 55032 Class B, EN 55024), FCC Class B, IP68, NEMA 4X, IK10, UL (for optional PoE injector and power adapter) |
Real-time Clock (RTC) | Yes |
Warranty | 3 Year(s) |
Comments | * cross-browser compatibility: Not available for H.265 video decoding and Intelligent Video settings; ** Edge Recording function is integrated with NVR 3 Corporate / NVR 3 Business / INR / GNR series. |
